Robot Visual Module 2D

1.3 megapixel 1/2” CMOS Gigabit Ethernet industrial area scan camera.

Performance

Sensor Type

CMOS, Global shutter

Sensor Model

OnSemi PYTHON1300

Pixel Size

4.8 µm × 4.8 µm

Chart Size

1/2”

Resolution

1280 × 1024

Max Framerate Rate

90 fps @1280 × 1024

Dynamic Range

59.6 dB

Signal to Noise Ratio

39.8 dB

Gain

0 dB ~ 15 dB

Time of Exposure

38 μs ~ 10 sec

62 μs ~ 10 sec

38 μs ~ 10 sec

Shutter Mode

Support mode: automatic exposure, manual exposure, one-click exposure

Color

Black & White

Color

Near-infrared

Pixel Format

Mono

8/10/10Packed/12/12Packed

Mono 8/10/12

Bayer RG

8/10/10Packed/12/12Packed

YUV422Packed，

YUV422_YUYV_Packed

RGB 8

Mono

8/10/10Packed/12/12Packed

Binning

Support: 1×1，1×2，1×4，2×1，2×2，2×4，4×1，4×2，4×4

Downsapling

Support: 1×1，2×2

Mirror Image

Support horizontal and vertical mirroring

Electrical Specification

Data Interface

Gigabit Ethernet(1000Mbit/s) Compatible: Fast Ethernet(100Mbit/s)

Digital I/O

6-pin P7 connector provides power supply and I/O: 1 optocoupler isolation input (Line0), 1 optocoupler isolation output (Line1), 1 bidirectional configurable and non-isolation I/O (Line 2).

Power Supply

12 VDC: PoE power is supported

Typical Power Consumption

2.7W@12VDC

Structure

Lens Mount

C-Mount

Overall dimension

29mm×29mm×42mm

Weight

About 68g

IP Grade

IP30 (Properly install the lens and cables)

Temperature

Operating temperature: 0℃~50℃，storage temperature: -30℃~70℃

Humidity

20%~80%RH, non-condensing

General Specifications

Software

MVS or third-party support: GigE Vision protocol software

Operating System

Windows XP/7/1032/64bits, Linux 32/64bits, MacOS 64bits

Protocol/Standard

GigE VisionV2.0，GenICam

Certificate

CE，FCC，RoHS，KC
